DUOS TEMP Wireless Transmitter 868 MHZ

Ref.: PA160410110
  • Case operation range –40 °C to 80°C
  • Temperature measurement sensor range*
  • Agrifood Industry compatibility
  • Compatible with Agrifood Industry Standards
  • Dual temperature probe
  • Internal and External probes
  • Wireless Link Strenght (RSSI)
  • Auto Discovery of the best wireless link
  • Low power and long battery life
  • Measuring and Transmitting battery voltage
  • Water Resistent
  • IP67 Protection



Radio Specifications
Range

Up to 4 Km LoS, 868MHz, 27 dBm (0.5 W)

*Range depends on the environment  and line of sight. Always verify your wireless network's range by performing a Site Survey.

Frequency Band

868.050 to 869.575 MHz

Operating Environment

-40ºC to 80ºC

Protection Index

IP67

Wireless Network
Maximum Devices (per gateway)

55

Communication Period

1 to 43200 seconds (configurable)

Temperature Measurement - External probe
Range

-40 to 125ºC

Resolution

0.1ºC

Accuracy

Typical: ± 0.25ºC / Maximum ± 0.5ºC

Supply Voltage
3x3.6 AA lithium batteries
3 years of estimated battery life

*Considering a communication period of 10 minutes, and maximum transmit power (27dBm) at 25ºC, with PN EVE ER14505M batteries.

Operating Conditions
-40 to 80ºC
Protection Index
IP67
